问题描述
RAID是SP686C-M-40i 4G
SP 1.16版本部署OS(kylin10.2)，SP没识别到盘，SP日志中有多处报错
环境信息
-
操作系统：部署Kylin 10.2
-
软件版本：Smart Provisioning 1.19
-
硬件配置：RAID SP686C-M-40i 4G
重现步骤
-
SP 部署OS
-
选盘界面没有硬盘
期望结果
正常部署OS
实际结果
未识别到盘
[2026-06-15 12:13:52,071 ERROR] (get_boot_name.py:1656)- Failed to find boot drives by hiraidadm. Failed to run command： hiraidadm c0:eNA:sNA show J
status code: 253
error info: {
"ToolInformation":{
"Name":"hiraidadm",
"Version":"1.2.2.9 ",
"BuildTime":"Jul 4 2025 11:03:05"
},
"CommandStatus":{
"StatusCode":-65539,
"Status":"Fail",
"Description":"Unsupported command."
},
"CommandData":{}
}
全部日志太长，所有ERROR日志：
行 134: 2026-03-26 14:17:33 Save the resources of server(with errors)...
行 151: [2026-03-26 14:17:36,579 ERROR] (common.py:377)- Failed to read /mnt/usb/spforbmc/spinfo/disksilk.json.
行 155: FileNotFoundError: [Errno 2] No such file or directory: '/mnt/usb/spforbmc/spinfo/disksilk.json'
行 160: [2026-03-26 14:17:38,131 ERROR] (boot_manage.py:59)- Invalid value or result.
行 167: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 168: ValueError: Failed to get drivers priority for BC83AMDA-5236C.
行 175: [2026-03-26 14:17:38,307 ERROR] (boot_manage.py:59)- Invalid value or result.
行 182: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 183: ValueError: Failed to get drivers priority for BC83AMDA-5236C.
行 185: [2026-03-26 14:17:40,078 ERROR] (get_boot_name.py:883)- Don't have RaidCard
行 195: [2026-03-26 14:17:43,650 ERROR] (ipmi_manage.py:174)- Failed to get device name from bdfInfo:0000:56:00.0, command: ipmitool raw 0x30 0x93 0xdb 0x07 0x00 0x40 0x08 0x02 0xc 0x30 0x30 0x30 0x30 0x3a 0x35 0x36 0x3a 0x30 0x30 0x2e 0x30, return：[1, 'Unable to send RAW command (channel=0x0 netfn=0x30 lun=0x0 cmd=0x93 rsp=0xd5): Command not supported in present state']
行 196: [2026-03-26 14:17:43,651 ERROR] (ipmi_manage.py:167)- Invalid root BDF format.
行 219: [2026-03-26 14:17:44,129 ERROR] (raid_common.py:140)- Failed to get raid info by sas3ircu.
行 235: [2026-03-26 14:17:45,525 ERROR] (san_boot_util.py:84)- can not find MZ520
行 243: [2026-03-26 14:17:45,606 ERROR] (raid_info.py:521)- HBA 9500-16i 0000:42:00.0 '' ['/opt/SmartProvisioning/app/raid_cfg/tools/sas3ircu', 'list', 'grep', '-i', '-A0', '-B0', 'HBA 9500-16i']
行 244: [2026-03-26 14:17:45,606 ERROR] (raid_base.py:74)- HBA 9500-16i 0000:42:00.0 Failed to obtain the controller index and PCIe.
行 245: [2026-03-26 14:17:45,606 ERROR] (raid_info.py:614)- HBA 9500-16i 0000:42:00.0 Failed to initialize the RAID controller card.
行 246: [2026-03-26 14:17:45,606 ERROR] (raid_manage.py:53)- Failed to obtain information of HBA 9500-16i raid card.
行 247: [2026-03-26 14:17:45,607 ERROR] (get_disk_info.py:1028)- raid card HBA 9500-16i pci 0000:42:00.0 initial failed.
行 301: [2026-03-26 14:17:45,853 ERROR] (compatibility_manage.py:521)- No driver or firmware file is uploaded.
行 302: [2026-03-26 14:17:45,853 ERROR] (compatibility_manage.py:386)- Upload error.
行 309: raise UploadError(compatibility_error_mesg)
行 310: os_install.compatibility_manage.UploadError: Compatibility check cannot be performed.
行 316: [2026-03-26 14:17:46,046 ERROR] (common.py:1785)- Failed to mount device(/dev/) to path(/mnt/CDROM/).
行 320: [2026-03-26 14:17:47,116 ERROR] (common.py:1808)- Failed to unmount /mnt/CDROM/.
行 323: [2026-03-26 14:17:47,116 ERROR] (scan_install.py:70)- check CD-ROM file failed
行 324: [2026-03-26 14:17:47,144 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 328: [2026-03-26 14:17:47.047 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Could not found valid CD/DVD drive device.. All tasks progress: 1/1
行 333: [2026-03-26 14:17:47.047 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 334: [2026-03-26 14:17:48.048 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 339: [2026-03-26 14:17:49.049 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 340: [2026-03-26 14:17:50.050 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 341: [2026-03-26 14:17:51.051 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 342: [2026-03-26 14:17:52.052 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 343: [2026-03-26 14:17:53.053 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 344: [2026-03-26 14:17:54.054 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 345: [2026-03-26 14:17:55.055 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 346: [2026-03-26 14:17:56.056 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 350: [2026-03-26 14:18:01.001 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 497: 2026-03-28 16:09:44 Save the resources of server(with errors)...
行 519: [2026-03-28 16:09:49,556 ERROR] (boot_manage.py:59)- Invalid value or result.
行 526: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 527: ValueError: Failed to get drivers priority for BC83AMDA-5236C.
行 534: [2026-03-28 16:09:49,740 ERROR] (boot_manage.py:59)- Invalid value or result.
行 541: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 542: ValueError: Failed to get drivers priority for BC83AMDA-5236C.
行 544: [2026-03-28 16:09:51,504 ERROR] (get_boot_name.py:883)- Don't have RaidCard
行 554: [2026-03-28 16:09:55,124 ERROR] (ipmi_manage.py:174)- Failed to get device name from bdfInfo:0000:56:00.0, command: ipmitool raw 0x30 0x93 0xdb 0x07 0x00 0x40 0x08 0x02 0xc 0x30 0x30 0x30 0x30 0x3a 0x35 0x36 0x3a 0x30 0x30 0x2e 0x30, return：[1, 'Unable to send RAW command (channel=0x0 netfn=0x30 lun=0x0 cmd=0x93 rsp=0xd5): Command not supported in present state']
行 555: [2026-03-28 16:09:55,125 ERROR] (ipmi_manage.py:167)- Invalid root BDF format.
行 578: [2026-03-28 16:09:55,593 ERROR] (raid_common.py:140)- Failed to get raid info by sas3ircu.
行 594: [2026-03-28 16:09:56,989 ERROR] (san_boot_util.py:84)- can not find MZ520
行 602: [2026-03-28 16:09:57,069 ERROR] (raid_info.py:521)- HBA 9500-16i 0000:42:00.0 '' ['/opt/SmartProvisioning/app/raid_cfg/tools/sas3ircu', 'list', 'grep', '-i', '-A0', '-B0', 'HBA 9500-16i']
行 603: [2026-03-28 16:09:57,069 ERROR] (raid_base.py:74)- HBA 9500-16i 0000:42:00.0 Failed to obtain the controller index and PCIe.
行 604: [2026-03-28 16:09:57,069 ERROR] (raid_info.py:614)- HBA 9500-16i 0000:42:00.0 Failed to initialize the RAID controller card.
行 605: [2026-03-28 16:09:57,070 ERROR] (raid_manage.py:53)- Failed to obtain information of HBA 9500-16i raid card.
行 606: [2026-03-28 16:09:57,070 ERROR] (get_disk_info.py:1028)- raid card HBA 9500-16i pci 0000:42:00.0 initial failed.
行 660: [2026-03-28 16:09:57,338 ERROR] (compatibility_manage.py:521)- No driver or firmware file is uploaded.
行 661: [2026-03-28 16:09:57,339 ERROR] (compatibility_manage.py:386)- Upload error.
行 668: raise UploadError(compatibility_error_mesg)
行 669: os_install.compatibility_manage.UploadError: Compatibility check cannot be performed.
行 675: [2026-03-28 16:09:57,532 ERROR] (common.py:1785)- Failed to mount device(/dev/) to path(/mnt/CDROM/).
行 679: [2026-03-28 16:09:58,597 ERROR] (common.py:1808)- Failed to unmount /mnt/CDROM/.
行 682: [2026-03-28 16:09:58,597 ERROR] (scan_install.py:70)- check CD-ROM file failed
行 683: [2026-03-28 16:09:58,625 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 687: [2026-03-28 16:10:00.000 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Could not found valid CD/DVD drive device.. All tasks progress: 1/1
行 692: [2026-03-28 16:10:00.000 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 697: [2026-03-28 16:10:01.001 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 698: [2026-03-28 16:10:02.002 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 699: [2026-03-28 16:10:03.003 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 700: [2026-03-28 16:10:04.004 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 701: [2026-03-28 16:10:05.005 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 704: [2026-03-28 16:10:06.006 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 705: [2026-03-28 16:10:06.006 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 706: [2026-03-28 16:10:07.007 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 707: [2026-03-28 16:10:08.008 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 708: [2026-03-28 16:10:09.009 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 872: [2026-06-09 14:15:01,180 ERROR] (boot_manage.py:59)- Invalid value or result.
行 879: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 880: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 887: [2026-06-09 14:15:01,460 ERROR] (boot_manage.py:59)- Invalid value or result.
行 894: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 895: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 901: [2026-06-09 14:15:01,542 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '55c', 'PD_Number': 11, 'VD_Number': 0, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 0, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50 ...
行 908: [2026-06-09 14:15:03,356 ERROR] (get_boot_name.py:1462)- not found first NVMe(44) on IO module 3.
行 910: [2026-06-09 14:15:03,536 ERROR] (scan_install.py:907)- Failed to check OS configuration file.
行 919: raise ValueError(error_msg)
行 920: ValueError: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.
行 921: [2026-06-09 14:15:03,565 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 925: [2026-06-09 14:15:04.004 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.. All tasks progress: 1/1
行 930: [2026-06-09 14:15:04.004 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 931: [2026-06-09 14:15:05.005 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 936: [2026-06-09 14:15:06.006 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 937: [2026-06-09 14:15:07.007 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 938: [2026-06-09 14:15:08.008 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 939: [2026-06-09 14:15:09.009 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 940: [2026-06-09 14:15:10.010 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 941: [2026-06-09 14:15:11.011 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 942: [2026-06-09 14:15:12.012 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 943: [2026-06-09 14:15:13.013 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 947: [2026-06-09 14:15:20.020 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 1106: [2026-06-09 14:41:03,131 ERROR] (boot_manage.py:59)- Invalid value or result.
行 1113: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 1114: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 1121: [2026-06-09 14:41:03,375 ERROR] (boot_manage.py:59)- Invalid value or result.
行 1128: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 1129: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 1135: [2026-06-09 14:41:03,450 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '51c', 'PD_Number': 11, 'VD_Number': 1, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 1, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50 ...
行 1159: [2026-06-09 14:41:03,906 ERROR] (raid_common.py:140)- Failed to get raid info by sas3ircu.
行 1173: [2026-06-09 14:41:04,995 ERROR] (san_boot_util.py:84)- can not find MZ520
行 1178: [2026-06-09 14:41:05,090 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '51c', 'PD_Number': 11, 'VD_Number': 1, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 1, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50 ...
行 1228: [2026-06-09 14:41:05,617 ERROR] (compatibility_manage.py:521)- No driver or firmware file is uploaded.
行 1229: [2026-06-09 14:41:05,618 ERROR] (compatibility_manage.py:386)- Upload error.
行 1236: raise UploadError(compatibility_error_mesg)
行 1237: os_install.compatibility_manage.UploadError: Compatibility check cannot be performed.
行 1270: [2026-06-09 14:41:11,419 INFO] (answer_revise.py:273)- Replace ks_onerror_script.cfg file successful.
行 1310: [2026-06-09 14:42:21.021 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1311: [2026-06-09 14:42:22.022 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1312: [2026-06-09 14:42:23.023 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1313: [2026-06-09 14:42:24.024 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1314: [2026-06-09 14:42:25.025 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1317: [2026-06-09 14:42:26.026 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1318: [2026-06-09 14:42:27.027 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1322: [2026-06-09 14:42:28.028 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1323: [2026-06-09 14:42:29.029 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1324: [2026-06-09 14:42:30.030 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1487: [2026-06-09 15:34:38,194 ERROR] (boot_manage.py:59)- Invalid value or result.
行 1494: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 1495: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 1502: [2026-06-09 15:34:38,450 ERROR] (boot_manage.py:59)- Invalid value or result.
行 1509: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 1510: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 1516: [2026-06-09 15:34:38,526 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '56c', 'PD_Number': 11, 'VD_Number': 1, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 1, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50 ...
行 1540: [2026-06-09 15:34:38,967 ERROR] (raid_common.py:140)- Failed to get raid info by sas3ircu.
行 1554: [2026-06-09 15:34:40,059 ERROR] (san_boot_util.py:84)- can not find MZ520
行 1559: [2026-06-09 15:34:40,150 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '56c', 'PD_Number': 11, 'VD_Number': 1, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 1, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50 ...
行 1609: [2026-06-09 15:34:40,669 ERROR] (compatibility_manage.py:521)- No driver or firmware file is uploaded.
行 1610: [2026-06-09 15:34:40,669 ERROR] (compatibility_manage.py:386)- Upload error.
行 1617: raise UploadError(compatibility_error_mesg)
行 1618: os_install.compatibility_manage.UploadError: Compatibility check cannot be performed.
行 1651: [2026-06-09 15:34:46,182 INFO] (answer_revise.py:273)- Replace ks_onerror_script.cfg file successful.
行 1691: [2026-06-09 15:35:51.051 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1692: [2026-06-09 15:35:52.052 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1693: [2026-06-09 15:35:53.053 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1694: [2026-06-09 15:35:54.054 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1695: [2026-06-09 15:35:55.055 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1696: [2026-06-09 15:35:56.056 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1699: [2026-06-09 15:35:57.057 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1703: [2026-06-09 15:35:58.058 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1704: [2026-06-09 15:35:59.059 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1705: [2026-06-09 15:36:00.000 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1861: [2026-06-13 14:13:56,382 ERROR] (boot_manage.py:59)- Invalid value or result.
行 1868: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 1869: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 1876: [2026-06-13 14:13:56,626 ERROR] (boot_manage.py:59)- Invalid value or result.
行 1883: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 1884: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 1890: [2026-06-13 14:13:56,711 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '55c', 'PD_Number': 13, 'VD_Number': 0, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 0, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50 ...
行 1897: [2026-06-13 14:13:58,638 ERROR] (get_boot_name.py:1462)- not found first NVMe(44) on IO module 3.
行 1899: [2026-06-13 14:13:58,814 ERROR] (scan_install.py:907)- Failed to check OS configuration file.
行 1908: raise ValueError(error_msg)
行 1909: ValueError: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.
行 1910: [2026-06-13 14:13:58,844 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 1914: [2026-06-13 14:14:00.000 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.. All tasks progress: 1/1
行 1919: [2026-06-13 14:14:00.000 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1924: [2026-06-13 14:14:01.001 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1925: [2026-06-13 14:14:02.002 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1926: [2026-06-13 14:14:03.003 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1927: [2026-06-13 14:14:04.004 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1928: [2026-06-13 14:14:05.005 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1929: [2026-06-13 14:14:06.006 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1930: [2026-06-13 14:14:07.007 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1931: [2026-06-13 14:14:08.008 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1932: [2026-06-13 14:14:09.009 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 1936: [2026-06-13 14:14:15.015 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 2088: [2026-06-13 15:06:14,911 ERROR] (boot_manage.py:59)- Invalid value or result.
行 2095: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 2096: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 2103: [2026-06-13 15:06:15,163 ERROR] (boot_manage.py:59)- Invalid value or result.
行 2110: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 2111: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 2117: [2026-06-13 15:06:15,240 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '54c', 'PD_Number': 13, 'VD_Number': 0, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 0, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50 ...
行 2124: [2026-06-13 15:06:17,051 ERROR] (get_boot_name.py:1462)- not found first NVMe(44) on IO module 3.
行 2126: [2026-06-13 15:06:17,227 ERROR] (scan_install.py:907)- Failed to check OS configuration file.
行 2135: raise ValueError(error_msg)
行 2136: ValueError: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.
行 2137: [2026-06-13 15:06:17,255 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 2141: [2026-06-13 15:06:19.019 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.. All tasks progress: 1/1
行 2146: [2026-06-13 15:06:19.019 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2151: [2026-06-13 15:06:20.020 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2152: [2026-06-13 15:06:21.021 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2153: [2026-06-13 15:06:22.022 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2154: [2026-06-13 15:06:23.023 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2155: [2026-06-13 15:06:24.024 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2156: [2026-06-13 15:06:25.025 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2157: [2026-06-13 15:06:26.026 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2158: [2026-06-13 15:06:27.027 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2159: [2026-06-13 15:06:28.028 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2163: [2026-06-13 15:06:34.034 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 2315: [2026-06-15 10:44:54,457 ERROR] (boot_manage.py:59)- Invalid value or result.
行 2322: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 2323: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 2330: [2026-06-15 10:44:54,701 ERROR] (boot_manage.py:59)- Invalid value or result.
行 2337: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 2338: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 2344: [2026-06-15 10:44:54,781 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '56c', 'PD_Number': 13, 'VD_Number': 0, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 0, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50 ...
行 2368: [2026-06-15 10:44:55,216 ERROR] (raid_common.py:140)- Failed to get raid info by sas3ircu.
行 2382: [2026-06-15 10:44:56,607 ERROR] (san_boot_util.py:84)- can not find MZ520
行 2387: [2026-06-15 10:44:56,989 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '56c', 'PD_Number': 13, 'VD_Number': 0, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 0, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50 ...
行 2496: [2026-06-15 10:44:57,572 ERROR] (scan_install.py:907)- Failed to check OS configuration file.
行 2503: raise ValueError(error_msg)
行 2504: ValueError: Disk(NA) capacity 0MB less than the required capacity 8192MB.
行 2505: [2026-06-15 10:44:57,603 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 2509: [2026-06-15 10:44:58.058 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Disk(NA) capacity 0MB less than the required capacity 8192MB.. All tasks progress: 1/1
行 2514: [2026-06-15 10:44:58.058 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2515: [2026-06-15 10:44:59.059 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2520: [2026-06-15 10:45:00.000 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2521: [2026-06-15 10:45:01.001 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2522: [2026-06-15 10:45:02.002 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2523: [2026-06-15 10:45:03.003 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2524: [2026-06-15 10:45:04.004 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2525: [2026-06-15 10:45:05.005 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2526: [2026-06-15 10:45:06.006 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2527: [2026-06-15 10:45:07.007 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2531: [2026-06-15 10:45:13.013 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 2685: [2026-06-15 11:09:36,674 ERROR] (boot_manage.py:59)- Invalid value or result.
行 2692: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 2693: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 2700: [2026-06-15 11:09:36,930 ERROR] (boot_manage.py:59)- Invalid value or result.
行 2707: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 2708: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 2714: [2026-06-15 11:09:37,011 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '54c', 'PD_Number': 4, 'VD_Number': 0, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 0, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50' ...
行 2715: [2026-06-15 11:09:37,024 ERROR] (get_boot_name.py:1656)- Failed to find boot drives by hiraidadm. Failed to run command： hiraidadm c0:eNA:sNA show J
行 2717: error info: {
行 2739: clear Clears an object, such as port errors, logs, and foreign configurations
行 2764: [2026-06-15 11:09:38,838 ERROR] (get_boot_name.py:1462)- not found first NVMe(44) on IO module 3.
行 2766: [2026-06-15 11:09:39,046 ERROR] (scan_install.py:907)- Failed to check OS configuration file.
行 2775: raise ValueError(error_msg)
行 2776: ValueError: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.
行 2777: [2026-06-15 11:09:39,074 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 2781: [2026-06-15 11:09:39.039 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.. All tasks progress: 1/1
行 2786: [2026-06-15 11:09:39.039 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2787: [2026-06-15 11:09:40.040 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2792: [2026-06-15 11:09:41.041 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2793: [2026-06-15 11:09:42.042 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2794: [2026-06-15 11:09:43.043 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2795: [2026-06-15 11:09:44.044 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2796: [2026-06-15 11:09:45.045 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2799: [2026-06-15 11:09:46.046 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 2800: [2026-06-15 11:09:46.046 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2801: [2026-06-15 11:09:47.047 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2802: [2026-06-15 11:09:48.048 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 2966: [2026-06-15 11:47:38,416 ERROR] (boot_manage.py:59)- Invalid value or result.
行 2973: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 2974: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 2981: [2026-06-15 11:47:38,612 ERROR] (boot_manage.py:59)- Invalid value or result.
行 2988: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 2989: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 2995: [2026-06-15 11:47:38,688 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '81c', 'PD_Number': 2, 'VD_Number': 0, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 0, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50' ...
行 2996: [2026-06-15 11:47:38,701 ERROR] (get_boot_name.py:1656)- Failed to find boot drives by hiraidadm. Failed to run command： hiraidadm c0:eNA:sNA show J
行 2998: error info: {
行 3020: clear Clears an object, such as port errors, logs, and foreign configurations
行 3044: [2026-06-15 11:47:38,863 ERROR] (scan_install.py:907)- Failed to check OS configuration file.
行 3053: raise ValueError(error_msg)
行 3054: ValueError: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.
行 3055: [2026-06-15 11:47:38,892 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 3059: [2026-06-15 11:47:40.040 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.. All tasks progress: 1/1
行 3064: [2026-06-15 11:47:40.040 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3069: [2026-06-15 11:47:41.041 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3070: [2026-06-15 11:47:42.042 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3071: [2026-06-15 11:47:43.043 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3072: [2026-06-15 11:47:44.044 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3073: [2026-06-15 11:47:45.045 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3075: [2026-06-15 11:47:46.046 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3077: [2026-06-15 11:47:46.046 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 3078: [2026-06-15 11:47:47.047 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3079: [2026-06-15 11:47:48.048 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3080: [2026-06-15 11:47:49.049 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3240: [2026-06-15 12:13:51,750 ERROR] (boot_manage.py:59)- Invalid value or result.
行 3247: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 3248: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 3255: [2026-06-15 12:13:51,978 ERROR] (boot_manage.py:59)- Invalid value or result.
行 3262: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 3263: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 3269: [2026-06-15 12:13:52,058 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '75c', 'PD_Number': 2, 'VD_Number': 0, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 0, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50' ...
行 3270: [2026-06-15 12:13:52,071 ERROR] (get_boot_name.py:1656)- Failed to find boot drives by hiraidadm. Failed to run command： hiraidadm c0:eNA:sNA show J
行 3272: error info: {
行 3294: clear Clears an object, such as port errors, logs, and foreign configurations
行 3318: [2026-06-15 12:13:52,218 ERROR] (scan_install.py:907)- Failed to check OS configuration file.
行 3327: raise ValueError(error_msg)
行 3328: ValueError: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.
行 3329: [2026-06-15 12:13:52,245 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 3333: [2026-06-15 12:13:53.053 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.. All tasks progress: 1/1
行 3338: [2026-06-15 12:13:53.053 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3343: [2026-06-15 12:13:54.054 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3344: [2026-06-15 12:13:55.055 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3345: [2026-06-15 12:13:56.056 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3346: [2026-06-15 12:13:57.057 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3347: [2026-06-15 12:13:58.058 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3349: [2026-06-15 12:13:59.059 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3351: [2026-06-15 12:14:00.000 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 3352: [2026-06-15 12:14:00.000 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3353: [2026-06-15 12:14:01.001 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3354: [2026-06-15 12:14:02.002 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3514: [2026-06-15 14:08:16,691 ERROR] (boot_manage.py:59)- Invalid value or result.
行 3521: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 3522: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 3529: [2026-06-15 14:08:16,903 ERROR] (boot_manage.py:59)- Invalid value or result.
行 3536: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 3537: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 3543: [2026-06-15 14:08:16,983 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '78c', 'PD_Number': 2, 'VD_Number': 1, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 1, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50' ...
行 3544: [2026-06-15 14:08:16,996 ERROR] (get_boot_name.py:1656)- Failed to find boot drives by hiraidadm. Failed to run command： hiraidadm c0:eNA:sNA show J
行 3546: error info: {
行 3568: clear Clears an object, such as port errors, logs, and foreign configurations
行 3592: [2026-06-15 14:08:17,147 ERROR] (scan_install.py:907)- Failed to check OS configuration file.
行 3601: raise ValueError(error_msg)
行 3602: ValueError: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.
行 3603: [2026-06-15 14:08:17,175 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 3607: [2026-06-15 14:08:19.019 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.. All tasks progress: 1/1
行 3612: [2026-06-15 14:08:19.019 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3617: [2026-06-15 14:08:20.020 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3618: [2026-06-15 14:08:21.021 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3619: [2026-06-15 14:08:22.022 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3620: [2026-06-15 14:08:23.023 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3621: [2026-06-15 14:08:24.024 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3624: [2026-06-15 14:08:24.024 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 3625: [2026-06-15 14:08:25.025 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3626: [2026-06-15 14:08:26.026 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3627: [2026-06-15 14:08:27.027 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3628: [2026-06-15 14:08:28.028 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 3770: [2026-06-15 14:24:25.025 ERROR] (os.SelectOsController:checkOsVersion:224)- OS version selected is NULL.
行 3806: [2026-06-15 14:24:40,968 ERROR] (raid_common.py:140)- Failed to get raid info by sas3ircu.
行 3820: [2026-06-15 14:24:42,040 ERROR] (san_boot_util.py:84)- can not find MZ520
行 3825: [2026-06-15 14:24:42,120 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '80c', 'PD_Number': 2, 'VD_Number': 1, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 1, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50' ...
行 3881: [2026-06-15 14:25:12.012 ERROR] (os.InstallOsController:selectOSViewButtonHandle:1449)- Select Os View is Invisible.
行 3892: [2026-06-15 14:25:36.036 ERROR] (os.InstallOsController:selectOSViewButtonHandle:1449)- Select Os View is Invisible.
行 3903: [2026-06-15 14:27:34.034 ERROR] (os.InstallOsController:selectOSViewButtonHandle:1449)- Select Os View is Invisible.
行 3935: [2026-06-15 14:27:38.038 ERROR] (os.InstallOsController:selectOSViewButtonHandle:1449)- Select Os View is Invisible.
行 3951: [2026-06-15 14:27:45.045 ERROR] (os.InstallOsController:selectOSViewButtonHandle:1449)- Select Os View is Invisible.
行 3958: [2026-06-15 14:27:45,830 ERROR] (compatibility_manage.py:386)- Upload error.
行 3965: raise UploadError(compatibility_error_mesg)
行 3966: UploadError: Compatibility check cannot be performed.
行 3979: [2026-06-15 14:28:08.008 ERROR] (os.InstallOsController:selectOSViewButtonHandle:1449)- Select Os View is Invisible.
行 3990: [2026-06-15 14:28:14.014 INFO ] (os.InstallOsController:changed:308)- Check Media Listen ErrorCode=0.
行 4005: [2026-06-15 14:28:31.031 ERROR] (os.InstallOsController:selectOSViewButtonHandle:1449)- Select Os View is Invisible.
行 4029: [2026-06-15 14:28:34,471 INFO] (answer_revise.py:273)- Replace ks_onerror_script.cfg file successful.
行 4077: [2026-06-15 14:30:32.032 ERROR] (os.UpgradeFirmwareDialogController:getFirmwareUpgradeResult:217)- The firmware upgrade result file content is empty.
行 4275: [2026-06-15 15:34:46,187 ERROR] (boot_manage.py:59)- Invalid value or result.
行 4282: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 4283: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 4290: [2026-06-15 15:34:46,387 ERROR] (boot_manage.py:59)- Invalid value or result.
行 4297: raise ValueError("Failed to get drivers priority for {}.".format(self._product_name))
行 4298: ValueError: Failed to get drivers priority for BC83AMDHB-5230Z.
行 4304: [2026-06-15 15:34:46,466 INFO] (hiraidadm_tool.py:395)- hiraid controllers information list: [{'ControllerId': 0, 'DeviceName': '/dev/bsg/hiraid9', 'PcieBusDomain': '0000', 'BusNumber': 'ab', 'DeviceNumber': '00', 'FunctionNumber': '00', 'PCIAddress': '0000:ab:00.0', 'SasAddress': '0x5c412ecaa0416000', 'FwVersion0': '2.5.19.6', 'FwVersion1': '2.5.19.6', 'VendorId': '19e5', 'DeviceId': '3758', 'SubVendorId': '19e5', 'SubDeviceId': '01ad', 'BoardSN': '036GJNE5S3004534', 'PF0': 'Enable', 'PF1': 'Disable', 'EP_PCIeWidth': 'NA', 'EP_PCIeSpeed': '4GT/s', 'ChipName': 'B80121', 'ChipVersion': 'V100', 'DieID': '49b89394 0081059d 00000000 00000000 001ee403 ', 'CurrentFW': 0, 'Tempature': '54c', 'PD_Number': 2, 'VD_Number': 1, 'VD_DegradeNumber': 0, 'VD_FaultNumber': 0, 'RaidNumber': 1, 'PreFailNumber': 0, 'FailNumber': 0, 'DDR_Size': '4096MB', 'DDR_ECC_Count': 0, 'DDR_ECC_BucketSize': 'NA', 'DDR_CE_Count': 0, 'DDR_UCE_Count': 0, 'SRAM_ECC_Count': 0, 'SRAM_UCE_Count': 0, 'CachePinned': 0, 'BoardError': 0, 'BoardClockError': 0, 'BoardPowerError': 0, 'BoardCapacityError': 0, 'BoardFlashError': 0, 'Board Name': 'SP686C-M-40i 4G', 'StatusCode': '0', 'CtrlMod': 'RAID', 'RgTaskSupport': 'rebuild,precopy,copyback,patrolread', 'ModSupport': 'raid,rawdrive', 'RaidLevelSupport': 'raid0,raid1,raid10,raid5,raid50,raid6,raid60', 'ExpanderSupport': 0, 'VDOpSupport': 'repair,expand,create,delete,front init,background init,fast init,sanitize,ccheck', 'PDOpSupport': 'sanitize,erase,smart_polling', 'MaxPDNumber': 40, 'MaxHDDNumber': 40, 'MaxSSDNumber': 40, 'MinHDDNumberRaid0': 1, 'MaxHDDNumberRaid0': 30, 'MinSSDNumberRaid0': 1, 'MaxSSDNumberRaid0': 30, 'MinHDDNumberRaid1': 2, 'MaxHDDNumberRaid1': 2, 'MinSSDNumberRaid1': 2, 'MaxSSDNumberRaid1': 2, 'MinHDDNumberRaid10': 4, 'MaxHDDNumberRaid10': 30, 'MaxHDDSubRgNumberRaid10': 15, 'MinSSDNumberRaid10': 4, 'MaxSSDNumberRaid10': 30, 'MaxSSDSubRgNumberRaid10': 15, 'MinHDDNumberRaid5': 3, 'MaxHDDNumberRaid5': 30, 'MinSSDNumberRaid5': 3, 'MaxSSDNumberRaid5': 30, 'MinHDDNumberRaid50' ...
行 4305: [2026-06-15 15:34:46,479 ERROR] (get_boot_name.py:1656)- Failed to find boot drives by hiraidadm. Failed to run command： hiraidadm c0:eNA:sNA show J
行 4307: error info: {
行 4329: clear Clears an object, such as port errors, logs, and foreign configurations
行 4353: [2026-06-15 15:34:46,663 ERROR] (scan_install.py:907)- Failed to check OS configuration file.
行 4362: raise ValueError(error_msg)
行 4363: ValueError: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.
行 4364: [2026-06-15 15:34:46,692 ERROR] (task_manager.py:400)- 1 '' ['python', '/opt/SmartProvisioning/app/send_cmd/scan_install.py', '/tmp/smartprovisioning/osinstall/osInstallRequest.json']
行 4368: [2026-06-15 15:34:48.048 INFO ] (spforbmc.ProgressTask:addOsInstallFinishTaskNum:757)- Operate system installation is failed, error message: Failed to get boot disk. Please insert the hard drives in the first two slots of the front- or rear-drive backplane of the chassis.. All tasks progress: 1/1
行 4373: [2026-06-15 15:34:48.048 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 4378: [2026-06-15 15:34:49.049 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 4379: [2026-06-15 15:34:50.050 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 4380: [2026-06-15 15:34:51.051 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 4381: [2026-06-15 15:34:52.052 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 4382: [2026-06-15 15:34:53.053 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 4385: [2026-06-15 15:34:54.054 INFO ] (spforbmc.BmcOperateController:call:304)- ListenAbortTask completed without error.
行 4386: [2026-06-15 15:34:54.054 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 4387: [2026-06-15 15:34:55.055 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 4388: [2026-06-15 15:34:56.056 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
行 4389: [2026-06-15 15:34:57.057 ERROR] (spforbmc.BmcOperateController:setRestartMode:157)- obtain active mode information from file failed.
答案内容由AI生成，仅供参考：
根据您提供的信息，问题描述为 Smart Provisioning 1.19 部署 Kylin 10.2 操作系统时，SP 选盘界面未识别到硬盘（RAID 卡为 SP686C-M-40i 4G），且 SP 日志中有多处报错。以下基于已有上下文进行综合分析。
点击此处查看详细分析解答
根据您提供的信息，问题描述为 Smart Provisioning 1.19 部署 Kylin 10.2 操作系统时，SP 选盘界面未识别到硬盘（RAID 卡为 SP686C-M-40i 4G），且 SP 日志中有多处报错。以下基于已有上下文进行综合分析。
可能原因分析（基于上下文信息）
1. 硬盘丝印（Silk）信息获取失败
- 在上下文文档块3（M.2 转接板硬盘信息无显示）中，系统日志出现
drive silk is userdata: NULL错误，表明系统未能成功获取硬盘的丝印信息，导致硬盘无法被正确识别。 - 该问题可能因环境未生成丝印文件导致，建议重启 OS 或检查
get_pcie_silk_config日志（关键字可在一键收集日志的app.log中查找）。
2. RAID 卡（SP686C）带内通信异常
- 文档块4（SP686C 获取不到 RAID 信息）指出：RAID 卡信息无法获取，物理盘未成功点灯到 RAID 卡下，日志中出现
Get BMC Mctp Info failed错误。 - 根本原因是 BMC 插卡与带内通信异常，分配不到 EID，导致后续流程阻塞。后续换插卡后问题消失 —— 该问题与您描述的 RAID 卡型号完全一致，且同样表现为硬盘信息缺失。
3. MCTP 协议栈问题
- 上下文知识图谱中提及
Get BMC Mctp Info failed等 MCTP 相关错误，可能影响 RAID 卡与 BMC 之间的信息交换，导致 SP 无法获取硬盘列表。
4. SPI Flash 或底层硬件就绪检查失败
- 上下文文档块1中
Spi Flash Notice指出 SPI 设备未就绪，可能影响固件加载和硬件初始化。
5. Smart Provisioning 版本兼容性
- 上下文提到 Smart Provisioning 存在多个版本（1.9.0、1.20.0、1.21.0 等），且部分版本（如 1.20.0.19）曾出现安装失败、SP Boot Failed 等事件。您使用的 SP 1.19 版本未在上下文中明确描述，但可参考相近版本的已知问题。
建议排查方向（基于上下文）
-
检查 BMC 日志中 MCTP 相关错误
查看app.log中是否有Get BMC Mctp Info failed或Mctp异常字样，若存在，优先确认 BMC 插卡与 RAID 卡之间的 MCTP 通信是否正常。 -
确认硬盘丝印信息是否生成
在一键收集日志中搜索get_pcie_silk_config，查看是否成功获取到硬盘的丝印信息。若drive silk is userdata: NULL持续上报，可尝试重启 OS 或检查 VPD 配置。 -
检查 BMC 时间与 SP 时间是否一致
上下文文档块2中指出，BMC 时间与实际时间差异过大（超过几个月）可能导致 SP 升级失败。虽然此条针对升级，但时间偏差也可能影响 SP 与 BMC 之间的认证或同步。 -
替换 BMC 插卡进行交叉验证
参考文档块4的结论：问题跟随 BMC 插卡走，换插卡后正常。若条件允许，可尝试更换 BMC 插卡以排除硬件通信问题。 -
检查 RAID 卡条带大小设置
上下文文档块5提到 SP686C 对不同类型硬盘支持的条带大小不同，若在组 RAID 时选择了不支持的条带大小，可能导致创建失败。虽然您未涉及组 RAID，但若 SP 部署过程中自动尝试组 RAID，也可能因该问题失败。
重要说明
- 以上分析均基于所提供的上下文信息，并非用户日志的直接定位。由于缺少用户的具体 SP 日志内容，无法确定具体是哪一类错误。
- 若上述方向均无法解决，建议按照文档块4的建议，收集完整 BMC 一键收集日志（含
app.log、storage组件日志），并联系华为工程师进一步分析。
结论：根据上下文，最可能的原因是 RAID 卡与 BMC 之间的 MCTP 通信异常（如文档块4所述），或硬盘丝印信息缺失（如文档块3所述）。请优先检查这两类日志。
看报错像是组了RAID后，未设置启动盘，导致没找到盘
只发ERROR日志有点局限，有时候需要联系上下文，这里可以传文件的
我的账号不清楚为什么无法上传一键收集日志附件，并且全量日志太长也没办法贴完全。今天把完整日志用邮件发送过去了，辛苦帮忙看一下。我们先按上面设置启动盘尝试一下
已发送
可以截个图看下BMC界面的存储管理页面，1880RAID卡下的硬盘状态吗？
你好，我无法上传图片，马上发到你邮箱
从截图来看，首先这个RAID卡名称显示的是9560-8i，不知道是否是界面显示问题
再看RAID卡下的盘，确实没有组RAID、设置启动盘，这样部署时确实无法选到部署盘
这个环境确实和提供日志的环境不一致。我们先确认一下首先尝试设置启动盘后是否能复现，然后如果有问题再收集日志+截图 邮件发送。验证此功能是否有什么要求？直通盘/RAID卡组硬盘场景是否理论上来说都能支撑？硬盘插槽是否有要求。问题较为紧急，感谢 感谢
直通盘场景、RAID卡组RAID场景都支持
直通盘槽位要求一般和硬件有关，通常是前两个槽位
RAID卡需要组RAID或设置成JBOD模式，但都需要设置启动盘
和RAID卡同事初步确认，新版本固件查询启动设备可能会出现NA的情况，这可能需要后期再对齐适配一下。
你们这边环境上固件版本是有配套要求吗？可以尝试降级到较低的版本，如 1.x.x.x 版本尝试一下
SP686C-M-40i 4G使用最新的固件版本：2.5.20.32，部署还是找不到启动盘，请确认新固件是否已支持。
